FEATURES
- Auto replacement function, reposition after person pass by
- Anti tail function auto-lock once turn 120°.
- Arms auto drop when power off, ensure unblock during emergency
- Standard electronic interface, remote control through Internet which is also could connect variety card readers and receive relay signal to work
- Diverse control mode optional, changeable due to varying to suit your requirement
- Auto alert error function, comfort for user maintain and operate (optional)
- Manual button or remote control, Bi-directional passage
- Open signal with memory or without set function (optional)
- Red and green light to show pass or stop, indication for Entrance and Exit
TECHNICAL SPECIFICATIONS
Model
NW-TS-01
NW-TS-02
NW-TS-06
Dimension
1200 x 280 x 980mm
330 x 420 x 980mm
1200 x 280 x 980mm
Power voltage
AC220±10%, 50Hz
AC220±10%, 50Hz
AC220±10%, 50Hz
Drive voltage
AC12V + AC18V
AC12V + AC18V
AC12V + AC18V
Operation condition
-15ºC ~ +60ºC
-15ºC ~ +60ºC
-15ºC ~ +60ºC
Relative humidity
None-condensation
None-condensation
None-condensation
Input signal
12v DC level or 12v pulse>100ms
12v DC level or 12v pulse>100ms
12v DC level or 12v pulse>100ms
Working current
≤2000mA
≤2000mA
≤2000mA
Length of the bar
510mm
510mm
510mm
Service life
≥5 million
≥5 million
≥5 million
Open angle
120º
120º
120º
Pass speed
≤30person/minute
≤30person/minute
≤30-40 person/minute
Structure
Frame or 304 Stainless steel cover
Frame or 304 Stainless steel cover
Frame or 304 Stainless steel cover
Open direction
Single and Bi-Directional (optional)
Single and Bi-Directional (optional)
Single and Bi-Directional (optional)
Work environment
Outdoor & indoor
Outdoor & indoor
Outdoor & indoor
IP Degree
IP43
IP43
IP54
Width of Passage
≤550mm
≤550mm
≤550mm
