FEATURES

Fault self-test and alarm functions, convenient user maintenance and using via the Built-in Controller Board, Programmable devices running status

Anti-Pinch mechanical structure, anti-bumps function, when the swing arm reset process meet resistance, within a limited time automatically stops the motor, the default delay after the reset again (until reset), and the force is very small (≤2Kg )

Anti-intrusion function, when the gate signal is not received, the arm will locked automatically.

With automatic reset function, after the gate opening, within a specified period of time not pass, the system will automatically cancel the user’s access Permissions

Adjustable normally open or normally closed, in order to meet the requirements of different venues

Compatible with a most reader device, integrate via dry contact signal

Unidirectional or bidirectional control of personnel access

Remote control and management by the management computer

Fail-Safe mode to meet fire safety requirements

Model: NW-SW-01

Size: 1400 x 200 x 980mm

Model: NW-SW-04

Size: 1400 x 180 x 965mm

Model: NW-SW-05

Size: 1400 x 180 x 965mm

TECHNICAL SPECIFICATIONS

Model

NW-SW-01

NW-SW-04

NW-SW-05

Dimension

1400 x 200 x 980mm

1400 x 180 x 965mm

Power voltage

AC220±10%, 50Hz

Drive voltage

AC12V + AC18V

Operation condition

-15ºC ~ +60ºC

Relative humidity

None-condensation

Input signal

12v DC level or 12v pulse>100ms

Working current

≤2000mA

Panel

Clear Acrylic

Service life

≥5 million

Communication Port

RS485

Pass speed

≤30person/minute

Structure

Frame or 304 Stainless steel cover

Open direction

Single and Bi-Directional (optional)

Gate opening & closing time

0.5s

IP Degree

IP54

Width of Passage

≤600mm

≤900mm
